Rated Voltage: AC100~240V 50/60Hz;<500W
Scanner: 40kppsfast scanning system, scan angle:±30°;Input signal:±5V;
Modulation:analog
Beam diameter and divergence: 5mm;<2mrad
Control mode: sound, auto, master-slave, DMX512(52CH), SD card, ILDA
Control Interface:international standard DMX 512,ILDA standard DB25 connector（Pangolin (USA), moncha, etc.)
Demonstration effect:built-in 160 pattern,SD card unlimited storage.
DMX effect: double pattern mode,and with the function of unique blanking,strobe, rotation, movement, zoom,write in,speed and color etc.
Control technology: ①RDM data bidirectional transmission ② SD card online upgrade ③temperature control system ④DMX512 upgrade
Operating requirement: dry, less dust, 10~35℃(environmental temperature),will reduce the attenuation of the diode and extend the life of the light.
Application:disco, club, medium indoor venue, theatre, etc.
Size:34 x 31 x 20cm N.W./G.W.:9.5/13kg
