◎Rated Voltage: AC100~240V 50/60Hz;≤100W
◎Scanner: 3W25K+,5W30KPPSfast scanning system, scan angle:max±30°;Input signal:±5V;
◎Modulation:analog
◎Beam diameter and divergence: 3*6.5mm;1.5mrad
◎Control mode: sound, auto, master-slave, DMX512(27/52CH), SD card, ILDA
◎Control Interface: 3 pin DMX512, 25DB ILDA
◎Demonstration effect: built-in 160 pattern,SD card unlimited storage.
◎DMX effect: double pattern mode,and with the function of unique blanking,strobe, rotation, movement, zoom, write in,speed and color etc.
◎Control technology: ①RDM data bidirectional transmission ② SD card online upgrade ③temperature control system ④DMX512 upgrade
◎Operating requirement: dry, less dust, 0~35℃(environmental temperature),will reduce the attenuation of the diode and extend the life of the light.
◎Application: disco, club, medium indoor venue, theatre, etc.
